Fully Automatic Laser Pocket Welting Machine

October 6, 2026 | 2:04 am

Automatic Laser Pocket Welting Machine

Fully Automatic Laser Pocket Welting Machine serviced by Tomsewing for Zipper in Bangladesh.The automatic garment pocket opening and sewing machine is an intelligent revolutionary product in the garment manufacturing industry. Equipped with laser cutting system and adaptive sewing technology, it can accurately complete the pocket opening and sewing process of various garments such as shirts, suits, pants and so on. Through the integrated design of automatic feeding, positioning and sewing, the average day of 2,000 + pieces of standardized production is achieved, the labor cost is reduced by 80%, and the sewing accuracy error is less than 0.5mm, which helps garment enterprises to quickly break through the bottleneck of production capacity.

Automatic garment pocket opening and sewing machine | efficient and accurate pocket opening and welting solution to achieve ±0.1mm sewing accuracy

24 hours continuous production

defective rate < 0.3%

support 23 kinds of shaped bags

Has served 100+ garment factories, single-machine daily output of 2,000 standard pocket,more than 500pcs automatic pocket welting machine running in the market with stable production capacity.

Fully Automatic Laser Pocket Welting Machine

Top 5 headache problems of clothing factory owners on garment pockets opening and sewing solution

1.Slow efficiency by hand sewing : skilled workers only complete 80 pieces per hour

2.Defective rate more than 8% : pocket corner skew/uneven stitches lead to rework

3.Complex pocket type needs to be adjusted frequently, wasting 2.5 hours per day

4.Efficiency of night shift e decreased by 30%, quality control was not sustainable

5.Thick and thin fabrics are difficult to adapt on other brands automatic laser pocket welting machine

Application Range

1.Large-scale clothing factory mass production

2.High-end custom studio

3.Outdoor sportswear manufacturer

Bartack round pocket

Double-lip pocket

Double-lip zipper pocket

Inside and outside single-lip pocket

Original side pocket

Pocket with a flap

Round pocket

Single-lip pocket

Single-lip slant pocket

Single-lip+double-lip zipper pocket

T-shirt placket

Zipper cap pocket

Zipper cap slant pocket

Zipper placket

Technical Parameters of Full Automatic Laser Pocket Welting Machine

Model	AXIS-3M	Presser Foot Lift Height	25mm
Rated Power	1.5Kw	Laser Power	150W
Rated Voltage	220V	Main Shaft Motor	Direct drive servo motor
Sewing Head	Flower Machine Head	Sewing Range Normal	Width:1-2.5cm Length:70-20cm
Stitch Length	0.1mm-12.7mm	Customized Sewing Scope	Width:0.8-0.9cm Length:30-70cm/20-22cm
Speed Setting	200-3000rpm/min	Air Pressure	0.5Mpa
Sewing Machine Needle	Dp×17（9#-18#）	Control System	Microcomputer control
Shuttle Bed	Pendulum,shuttle	System Language Support	Chinese;English;Korea;Japanese;Turkish;Vietnamese;Portuguese
Machine Weight	850kg	Machine Size	210132153cm(LengthWidthHeight)
